| Feature | Description |
|---|---|
|
Pressing power |
40 kN
|
|
Specific pressing power |
11.2 N/cm²
|
|
Driving power |
1.1 kW
|
|
Voltage / Frequency |
230 V / 50 Hz
|
|
Cycle time when idling |
27 s
|
|
Loading height |
661 mm
|
|
Loading aperture width x height |
700 x 470 mm
|
|
Bale length from to x Bale width x Bale height |
700 x 500 x 600 mm
|
|
Bale weight |
60 Kg Approx
|
|
Machine Width x Depth x Height |
1020 x 812 x 1922 mm |
|
Machine Weight |
290 Kgs
|
|
Method of strapping |
Vertical
|
|
Number of strappings |
2
|
|
Type of consumables |
Strapping tape |
| Feature | Description |
|---|---|
|
Pressing power |
120 kN
|
|
Specific pressing power |
25 N/cm²
|
|
Driving power |
3 kW
|
|
Voltage / Frequency |
400 V / 50 Hz
|
|
Cycle time when idling |
22 s
|
|
Loading aperture width x height |
800 x 495 mm
|
|
Bale length from to x Bale width x Bale height |
800 x 600 x 600 mm
|
|
Bale weight |
100 Kg Approx
|
|
Machine Width x Depth x Height |
1198 x 823 x 1986 mm
|
|
Machine Weight |
540 Kgs
|
|
Method of strapping |
Vertical
|
|
Number of strappings |
3
|
|
Type of consumables |
Strapping tape
|
|
Industry type |
Logistics & Distribution, Manufacturing, Print & Packaging
|
| Feature | Description |
|---|---|
|
Pressing power |
178 kN
|
|
Specific pressing power |
19,23 N/cm²
|
|
Driving power |
4 kW
|
|
Voltage / Frequency |
400 V / 50 Hz
|
|
Cycle time when idling |
23s |
|
Loading height |
928 mm
|
|
Loading aperture width x height |
1195 x 558 mm |
|
Bale length from to x Bale width x Bale height |
1200 x 780 x 1000 mm
|
|
Hourly Output in Balers |
2-5 bales Approx.
|
|
Bale weight |
250 Kg Approx. |
|
Machine Width x Depth x Height |
1700 x 1075 x 2499 mm
|
|
Machine Weight |
1300 Kgs
|
|
Method of strapping |
Vertical
|
|
Number of strappings |
4 |
| Feature | Description |
|---|---|
|
Pressing power |
594 kN |
|
Specific pressing power |
63,46 N/cm²
|
|
Driving power |
4 kW
|
|
Voltage / Frequency |
400 V / 50 Hz
|
|
Cycle time when idling |
25 s
|
|
Loading height |
1195 x 650 mm
|
|
Loading aperture width x height |
1200 x 780 x 1200 mm
|
|
Bale length from to x Bale width x Bale height |
1110 mm
|
|
Hourly Output in Balers |
1-2 bales Approx.
|
|
Bale weight |
480 Kg Approx.
|
|
Machine Width x Depth x Height |
1797 x 1247 x 2985 mm
|
|
Machine Weight |
2083 Kgs
|
|
Method of strapping |
Vertical
|
|
Number of strappings |
4 |
